Key features and benefits:
• Small footprint—With dimensions of 19 cm wide and 39 cm deep, you can fit the MiniAmp Thermal Cycler almost anywhere. And because its airflow is front to back, you can set multiple units side by side to save valuable bench space.
• 5-inch intuitive color touchscreen—for easy programming and training of new users
• WiFi-enabled and accessible by Thermo Fisher Connect—giving you the freedom to design and securely upload your methods from any mobile device or desktop computer
Thermal Accuracy | ±0.25°C (35°C to 99.9°C) |
High-throughput Compatibility | High-throughput Compatible |
For Use With (Equipment) | Applied Biosystems GeneAmp plastics consumables |
Thermal Uniformity | <0.5°C (20 sec. after reaching 95°C) |
Reaction Speed | Fast, Standard |
Dimensions | 15.4 x 7.5 x 7.9 in. (39 x 19 x 20 cm) |
Capacity |
96-well, 0.2 mL
|
Voltage | 100/240 V |
Display Type | 5 in. Color TFT LCD Touchscreen |
Product Type | Thermal Cycler |
Warranty |
Limited Warranty
|
Thermal Range |
0°C to 100°C
|
User Interface |
USB, Wi-Fi, Ethernet
|
Wattage | 500 W |
Max. Ramp Rate | 3°C/sec. (Block), 2.2°C/sec. (Sample) |
No. of Programs | >1000 |
Weight |
13 lb. (5.9 kg)
|
Block Configurations |
96-well
|
Unit Size | 1 instrument |
